Smyg1
Gold Member | Редактировать | Профиль | Сообщение | ICQ | Цитировать | Сообщить модератору
Hubble LT первый раз такой зонник вижу...
это он три зоны отключил сам в начале?
Цитата: WDC WD1600LPVX-00V0TT0 FW:06.1TJ SN:WDC-ROM SN_ XYZ----
Logical: Cyls 16383, Heads 16, Sectors 63, LBA 310988160, Logical:512, Physical:4096, 159Gb
Controller Buffer Size: 16384Kb
Family:Hubble LT
SECTOR LOGICAL ZONE DATA TABLE
------------------------------
# FirstLBA LastLBA SPT0 SPT1
----------------------------------------
0 0 0 59D 0
1 0 12894D7F 11E 0
2 0 12894D7F 11C 0
3 0 12894D7F 11A 0
4 0 678D3F 112 0
5 678D40 B5123F 110 0
6 B51240 12A7DEF 109 0
7 12A7DF0 192150F 10C 0
8 1921510 2049F07 108 0
9 2049F08 229F9DF 108 0
10 229F9E0 29E99E7 106 0
11 29E99E8 309CCC7 107 0
12 309CCC8 37C55F7 102 0
13 37C55F8 3ED0D0F 100 0
14 3ED0D10 45D170F FD 0
15 45D1710 4CDB28F FC 0
16 4CDB290 53828B7 FC 0
17 53828B8 5A41A4F FA 0
18 5A41A50 6111C1F F5 0
19 6111C20 67C6C9F F0 0
20 67C6CA0 6E6C50F F0 0
21 6E6C510 74D186F EC 0
22 74D1870 7B1B057 E8 0
23 7B1B058 8156A57 E6 0
24 8156A58 87790BF E3 0
25 87790C0 8D814CF E1 0
26 8D814D0 931785F E3 0
27 9317860 9896C67 E1 0
28 9896C68 9E7EFE7 DC 0
29 9E7EFE8 A1CB5EF DC 0
30 A1CB5F0 A6C51C7 DA 0
31 A6C51C8 ABC205F D7 0
32 ABC2060 B165C2F D2 0
33 B165C30 B6FB53F D0 0
34 B6FB540 BC75D3F CC 0
35 BC75D40 C1B9B17 CB 0
36 C1B9B18 C6E5ABF C5 0
37 C6E5AC0 CBF008F C0 0
38 CBF0090 D0ECF7F BE 0
39 D0ECF80 D5E9E2F BE 0
40 D5E9E30 DACF55F BB 0
41 DACF560 DF85107 B9 0
42 DF85108 E3FE77F B9 0
43 E3FE780 E884A87 B4 0
44 E884A88 ED23807 B0 0
45 ED23808 F1BA85F AF 0
46 F1BA860 F63650F AB 0
47 F636510 FA9E987 A8 0
48 FA9E988 FE55EE7 A7 0
49 FE55EE8 101F1DF7 A1 0
50 101F1DF8 103F178F A2 0
51 103F1790 107FE4C7 9E 0
52 107FE4C8 10BE3CC7 98 0
53 10BE3CC8 10FAF0C7 94 0
54 10FAF0C8 1137A4BF 94 0
55 1137A4C0 11731DBF 91 0
56 11731DC0 11AE2DBF 90 0
57 11AE2DC0 11E8D48F 8F 0
58 11E8D490 12231247 8E 0
59 12231248 125CC76F 8C 0
60 125CC770 12894D7F 8A 0
Capacity:159Gb
max_LBA_for_head_0 = 14F82A80 - 180Gb
max_user_cyls_for_head_0 = 31E55
max_virt_cyls_for_head_0 = 33971
max_LBA_for_head_1 = 0 - 0
max_user_cyls_for_head_1 = 0
max_virt_cyls_for_head_1 = 0
Hd0 TPI = 09 09 09 0A 0B 0B 0B 0B 0C 0D 0D 0D 0D 0E 0E 0E 0E 0E 0E 0F 0F 0F 0F 0F 0F 10 10 10 10 10 10 10 10 10 10 0F 0F 0F 0F 0F 0F 0F 0F 0F 0F 0F 0F 0F 0F 0F 0E 0D 0D 0D 0D 0D 0D 0D 0C 0B
Hd0 KFCI = 12 12 12 15 16 18 16 17 17 18 17 18 18 19 19 18 18 19 1A 1A 1A 1B 1B 1B 1B 1A 1A 1B 1A 1A 1A 1B 1B 1C 1B 1C 1C 1C 1B 1B 1B 1A 1B 1C 1B 1C 1C 1B 1D 1B 1B 1C 1C 1B 1C 1B 1A 19 18 17
Hd1 TPI = 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Hd1 KFCI = 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
Total Time: 24:32:17
-----------------------------------------------------
1 3307 0 0 1 1 00:00:13 00:00:13
2 3309 0 0 1 1 00:02:18 00:02:18
3 D8 D8 0 1 1 00:00:07 00:00:07
4 34D1 0 0 1 1 00:45:48 00:45:48
5 3514 0 0 1 1 00:02:29 00:02:29
6 34D2 0 0 1 1 00:44:54 00:44:54
7 34D3 0 0 1 1 00:00:23 00:00:23
8 34D4 0 0 1 1 05:33:06 05:33:06
9 34D4 0 0 1 1 03:38:15 03:38:15
10 34D4 0 0 1 1 04:12:09 04:12:09
11 34D6 0 0 1 1 05:06:30 05:06:30
12 D5 0 0 1 1 02:05:06 02:05:06
13 D4 D4 0 1 1 00:00:11 00:00:11
14 D4 D4 0 1 1 00:00:11 00:00:11
15 D4 D4 0 1 1 00:00:15 00:00:15
16 3300 0 0 1 1 00:00:38 00:00:38
17 3301 0 0 1 1 00:00:08 00:00:08
18 3402 0 0 1 1 00:00:33 00:00:33
19 D7 D7 0 1 1 00:01:04 00:01:04
20 B9 B9 0 1 1 00:38:25 00:38:25
21 3422 0 0 1 1 00:11:44 00:11:44
22 3423 0 0 1 1 00:00:44 00:00:44
23 BA BA 0 1 1 00:37:29 00:37:29
24 3422 0 0 1 1 00:11:43 00:11:43
25 3423 0 0 1 1 00:00:28 00:00:28
26 B9 B9 0 1 1 00:37:26 00:37:26
-----------------------------------------------------
Total Times (calculated) 24:32:17 24:32:17
B5 - WRRO Result
---------------------------------
Number of Records : 20
Starting Time : 00:00:01
Ending Time : 03:36:44
Head 0 all : 20
WrWrro : 8
RdWrro : 12
BadWrroWr : 7
BadWrroRd : 13
TrackMapOut : 13
WedgePushDown : 7
Surface Log Errors
Head 0 = 51044 ( 95%), Tracks: 24841 , Sectors: 26203 , Max: 53330
Surface Log Errors by Head by Zone
P-List
Head 0 = 34494 , Tracks:23840 , Sectors:10654
------------------------------------------------
All = 34494 , Tracks:23840 , Sectors:10654 , Max 153337, 22% |
 |
Всего записей: 5906 | Зарегистр. 03-10-2006 | Отправлено: 10:23 27-11-2023 | Исправлено: Smyg1, 14:14 27-11-2023 |
|
